2.2.6 Bit Image Commands
ESC * m n1 n2 [d] k
CT-S280 CT-S300 CT-S2000 CT-S4000 BD2-2220 PMU series
Supportmodel
CT-S281
CT-S310 CT-S801/851 CT-S601/651 CT-P29x series CT-S310II
[Function] Specifying the bit image mode
[Code] <1B>H<2A>H<m>H<n1><n2>[<d>] k
[Range] m=0, 1, 32, 33
0≤n1≤255, 0≤n2≤2
0≤d≤255
k=n1+256×n2 (m=0,1),k=(n1+256×n2)×3 (m=32, 33)
[Outline] [The specification which is commontothemodel]
•Accordingtothe number of dots specifiedin“n1”, “n2”,specify thebitimage ofmode “m”.
• The number ofdots printed isdivided by 256, whose quotient istaken as n2 and residual as “n1”. The total
numberof dots printed inthehorizontal directionisequal ton1+(256×n2).
•When bitimage data have beeninput inexcess of dotpositionsthat canbeprintedonone line, theexcess
data are discarded.
•”d”is bit image data.Bits to beprintedare specifiedas“1”andthose not as “0”.
•The bit image modes specified by “m”are shownasfollows:
Vertical Direction HorizontalDirection
m Mode
Dot Count DotDensity DotDensity
Maximum
Dot Count
0 8dotsingle density 8 67dpi 101dpi (1)
1 8dotdouble density 8 67dpi 203dpi (2)
32 24dotsingle density 24 203dpi 101dpi (3)
33 24dot double density 24 203dpi 203dpi (4)
[The specification which depend on the model] (1) -(4) unit: dpi
supportmodel
paper
width
print
width
(1) (2) (3) (4)
CT-S4000 112mm 104mm 416 832 416 832
CT-S4000 112mm 90mm 360 720 360 720
CT-S4000 83mm 82.5mm 330 660 330 660
CT-S2000/CT-S801/CT-S851/CT-S601/CT-S651 83mm 80mm 320 640 320 640
CT-S300/CT-S310/CT-S2000/CT-S4000 CT-S801/CT-S851
CT-S601/CT-S651/BD2-2220/PMU series/CT-P292/293/CT-S310II
80mm 72mm 286 576 286 576
CT-S801/CT-S601/CT-S310II 80mm 68.25mm 273 546 273 546
CT-S300/CT-S310/CT-S2000/CT-S4000/
CT-S801/CT-S851/CT-S601/CT-S651/CT-S310II
80mm 64mm 256 512 256 512
CT-S2000/CT-S801/CT-S601 60mm 54.5mm 218 436 218 436
CT-S2000/CT-S4000/CT-S801/CT-S851/CT-S601/CT-S651
BD2-2220/PMU2XXX/PMU2XXXII
58mm 54mm 216 432 216 432
CT-S2000/CT-S801/CT-S851/CT-S601/CT-S651/CT-S310II 58mm 52.5mm 210 420 210 420
CT-P290/291 58mm 51mm 204 408 204 408
CT-S801/CT-S851/CT-S601/CT-S651/CT-S310II 58mm 48.75mm 195 390 195 390
CT-S280/CT-S281/CT-S300/CT-S310/CT-S2000/
CT-S801/CT-S851/CT-S601/CT-S651/CT-P290/291/292/293/
CT-S310II
58mm 48mm 192 384 192 384
CT-S300/CT-S310/CT-S2000/CT-S4000
CT-S801/CT-S851/CT-S601/CT-S651/CT-S310II
58mm 45mm 180 360 180 360
[Caution] • Whenthe value of “m”is outofthe above range,thedata followingafter “n1”is processed as
normalprintingdata.
