- 423 -
4.2.7 MSW7
●MSW7-1: Baud rate
[Outline] Selects thebaud rate whichisserial interfacecommunicationcondition.
Enabled ifDSW1-1 OFFis set [followingmemoryswitch setting] .
Setting Value
Baud Rate
1200bps,2400bps,4800bps,9600bps,19200bps,
38400bps,57600bps,115200bps
●MSW7-2: Data length
[Outline] Selects thedata length,whichisa serialinterface communicationcondition.
Enabled ifDSW1-1 OFFis set [followingmemoryswitch setting] .
Setting Value
Data Length 7bits,8bits
●MSW7-3: Stop bit
[Outline] Selects thestop bit, whichisa serialinterface communicationcondition.
Enabled ifDSW1-1 OFFis set [followingmemoryswitch setting] .
Setting Value
Stop Bit 1bit,2bits
●MSW7-4: Parity
[Outline] Selects theparity,which is aserial interface communicationcondition.
Enabled ifDSW1-1 OFFis set [followingmemoryswitch setting] .
Setting Value
Parity NONE,ODD, EVEN
●MSW7-5: Flow control
[Outline] Selects theflow control, whichisa serialinterfacecommunication condition.
Enabled ifDSW1-1 OFFis set [followingmemoryswitch setting] .
Setting Value
Flow Control DTR/DSR, XON/XOFF
