fn=5, 53: Function 5 Sending Key Code List of Stored Record
GS ( C pL pH m fn b
[Code] <1D>H<28>H<43>H<pL><pH><m><fn><b>
[Range] (pL+pH×256)=3 (pL=3,pH=0)
m=0
fn=5,53
b=0
[Outline] [The specification which is commontothemodel]
•Sends keycodelistofrecord existing inuserNV memory.
Hex. Decimal Data size
Header 37H 55 1byte
Identifier 71H 113 1byte
Status 40Hor41H 64or65 1byte
Data 20HtoFEH 32to254 2to 80bytes
NUL 00H 0 1byte
•Data isa data group witha list ofkey codes.
Transmissiondata group whenrecord isnot detected isasshown below.
Hex. Decimal Data Size
Header 37H 55 1byte
Identifier 71H 113 1byte
Status 40H 64 1byte
NUL 00H 0 1byte
•After sending [Header -NUL] ,receives aresponse from thehostandexecutesthenext processing
correspondingtothe response.
Incase of“Status (with continuous block): hexadecimalnumber =41H /decimal number =65”
Response
ASCII Decimal
Content of Processing
ACK 6 Sends next data group.
NAK 21 Resends previous data group.
CAN 24 Cancelsprocessing.
Incase of“Status (last block): hexadecimalnumber =40H /decimal number =64”
Response
ASCII Decimal
Content of Processing
ACK 6 Terminates processing.
NAK 21 Resends previous data group.
CAN 24 Cancelsprocessing.
