Citizen CT-S280 - Fn=3, 51: Function 51 Sending the Remaining Amount of NV Graphics Memory

- 159 -
fn=3, 51: Function 51 Sending the Remaining Amount of NV Graphics Memory
GS ( L pL pH m fn
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn>
[Range] (pL+pH×256)=2 (pL=2,pH=0)
m=48
fn=3,51
[Outline] [The specification which is commontothemodel]
•Sends theremaining amount of NV graphics area (number ofbytes of unused area).
Hex. Decimal Data Size
Header 37H 55 1byte
Identifier 31H 49 1byte
Data 30Hto39H 48to57 1to 6bytes
NUL 00H 0 1 byte
•Convertsthe remainingamount tocharactercode expressed in decimalnotationand sends it from higher
digit.
•Data size is variable.
