Citizen CT-S280 - DLE DC4 Fn M T (Specification of Fn = 1)

- 330 -
DLE DC4 fn m t (Specification of fn = 1)
CT-S280 CT-S300 CT-S2000 CT-S4000 BD2-2220 PMUseries
Supportmodel
CT-S281
CT-S310 CT-S801/851 CT-S601/651 CT-P29x series CT-S310II
[Function] Outputting specified pulse in real-time
[Code] <10>H<14>H<fn><d1>…<d7>
[Range] fn=1,m=1,2 t=d3=20, d4=1, d5=6,d6=2,d7=8
[Outline] [The specification which is commontothemodel]
•A signal specified with“t”is output totheconnectorpinspecified with“m”.
m Connector Pin
0
Pin No. 2of drawerkick-out connector
1
Pin No. 5of drawerkick-out connector
•Set the ONtime/OFF time to tx100 ms,respectively.
[Caution] [The specification which is commontothemodel]
•Whenreceivingacoderowcoincidingwiththecodeconfiguringthiscommand,the
sameoperationasthiscommandtakesplaceandattentionbytheuserisrequired.
Example:Whencorrespondingcoderowispresentinbitimagedata.
•Thiscommandmustnotbeusedbetweenothercommandcoderows.
Example:Thiscommandisusedinthebitimagedata.
•Thiscommandisignoredunderthefollowingconditions.
•Duringsendingblockdata
•Duringoutputofsignaltodrawerkickconnector
•Duringoccurrenceoferror
[See Also] ESC p
