Citizen CT-S280 - Fn=11: Function 11 Setting Communication Conditions

- 300 -
fn=11: Function 11 Setting Communication Conditions
GS ( E pL pH fn a d1...dk
[Code] <1D>H<28>H<45>H<pL><pH><fn><a><d1>...<dk>
[Range] 3≤(pL+pH×256)≤65535(0≤pL≤255, 0≤pH≤255)
fn=11
1≤a≤4 (Notchanged inother thanspecified range)
48≤d≤57 (Notchanged inother thanspecified range)
1≤k≤6
[Outline] [The specification which is commontothemodel]
•Sets thecommunication conditionsof serialinterface specifiedby“a”.
•a=1:Settingbaud rate
Baud Rate d1 d2 d3 d4 d5 d6
1200◎ 49(“1”) 50(“2”) 48(“0”) 48(“0”) - -
2400 50(“2”) 52(“4”) 48(“0”) 48(“0”) - -
4800 52(“4”) 56(“8”) 48(“0”) 48(“0”) - -
9600▲ 57(“9”) 54(“6”) 48(“0”) 48(“0”) - -
19200△ 49(“1”) 57(“9”) 50(“2”) 48(“0”) 48(“0”) -
38400 51(“3”) 56(“8”) 52(“4”) 48(“0”) 48(“0”) -
●57600 53(“5”) 55(“7”) 54(“6”) 48(“0”) 48(“0”) -
●115200 49(“1”) 49(“1”) 53(“5”) 50(“2”) 48(“0”) 48(“0”)
◎---support byCT-S280,CT-S281,CT-S2000,CT-S4000,CT-S801,CT-S851,CT-S601,CT-S651,CT-S310II
●---support by CT-S280,CT-S2000, CT-S4000,CT-S801,CT-S851,CT-S601,CT-S651, PMUseries,CT-S310II
*PMU2XXX:Prohibitthe use of 57600.CT-P29xseries doesnotsupport115200bps.
△---Default : CT-S300,CT-S310,CT-S2000(JPN/EUR),CT-S4000(JPN/EUR)
▲---Default :CT-S280,CT-S281,CT-S2000(USA),CT-S4000(USA),CT-S801,CT-S851,CT-S601,CT-S651,
BD2-2220,PMUseries,CT-P29x series,CT-S310II
•a=2:Settingtospecified parity
d1 Parity Setting
48(Default) No parity
49 Oddparity
50 Evenparity
•a=3:Settingtospecified flow control
d1 Flow Control
48(Default) DSR/DTR
49 XON/XOFF
•a=4:Settingtospecified data length
d1 Setting Data Length
55 7-bit length
56(Default) 8-bit length
•Operates onlyinprinter function setting mode.
• Which of dip SW or memory SW is used at initialization depends on “Selecting communication condition
setting” of dipSW1-1.
