Citizen CT-S280 - Fn=8: Function 8 Defining Data by the Column Format to Character Code Page of Work Area

- 297 -
fn=8: Function 8 Defining Data by the Column Format to Character Code Page of Work Area
GS ( E pL pH fn y c1 c2 [xd1...d(y×x)] k
[Code] <1D>H<28>H<45>H<pL><pH><fn><y><c1><c2>[<x><d1>..<d(yXx)>]<k>
[Range] 5≤(pL+pH×256)≤65535
fn=8
y=2(At selectionoffont C)
y=3(At selectionofother thanfontC)
128≤c1≤c2≤255
0≤x≤12(At selectionoffont A)
0≤x≤9(At selection of fontB)
0≤x≤8(At selection of fontC)
0≤d≤255
k=c2-c1+1
[Outline] [The specification which is commontothemodel]
•Defines the data in column format inunitsofcharacter on thecode page in RAM.
•Operates onlyinprinter function setting mode.
Data structure(9×17)
d1d4……………………d25
d3d6……………………d27
bit7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
○ ○ ○ ○ ○ ○ ○ ○ ○
○ ○ ○ ○ ○ ○ ○ ○ ○
● ○ ○ ○ ● ● ○ ● ●
● ○ ● ○ ○ ○ ○ ○ ○
● ○ ○ ○ ○ ● ○ ○ ○
● ● ○ ● ○ ● ○ ○ ●
○ ○ ● ○ ● ● ● ○ ○
○ ○ ○ ○ ○ ○ ○ ○ ○
○ ○ ○ ○ ○ ○ ○ ○ ○
○ ● ○ ○ ○ ● ○ ● ○
● ○ ● ○ ● ○ ○ ○ ○
● ○ ○ ● ○ ○ ● ○ ●
● ● ○ ○ ○ ● ○ ● ●
○ ○ ● ○ ○ ○ ○ ○ ○
○ ○ ○ ○ ○ ○ ○ ○ ○
○ ○ ○ ○ ○ ○ ○ ○ ○
○ ○ ○ ● ● ○ ○ ○ ○
● ○ ● ○ ○ ● ● ● ○
● ● ○ ● ○ ○ ● ○ ●
○ ● ○ ○ ● ○ ○ ○ ○
● ● ● ○ ○ ○ ○ ● ○
○ ○ ○ ● ○ ● ○ ○ ●
○ ○ ○ ○ ○ ○ ○ ○ ○
Bits 6through0 are not character data
