Citizen CT-S280 - Fn=0, 48: Function 48 Sending NV Graphics Memory Capacity; Fn=2, 50: Function 50 Printing Graphics Data Stored in Print Buffer

- 158 -
fn=0, 48: Function 48 Sending NV Graphics Memory Capacity
GS ( L pL pH m fn
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn>
[Range] (pL+pH×256)=2 (pL=2,pH=0)
m=48
fn=0,48
[Outline] [The specification which is commontothemodel]
•Sends allcapacityofNV graphicsarea inthe numberof bytes.
Hex. Decimal Data Size
Header 37H 55 1byte
Identifier 30H 48 1byte
Data 30Hto39H 48to57 1to 6bytes
NUL 00H 0 1 byte
•Convertsall capacitytocharacter code expressed in decimalnotationand sends it from higher digit.
•Data size is variable.
• All definition area can be specified by GS ( E out of [0, 64K, 128K, 192K, 256K, 320K, and 384K] . Default
value is384k bytes
fn=2, 50: Function 50 Printing Graphics Data Stored in Print Buffer
GS ( L pL pH m fn
[Code] <1D>H<28>H<4C>H<pL><pH><m><fn>
[Range] (pL+pH×256)=2 (pL=2,pH=0)
m=48
fn=2,50
[Outline] [The specification which is commontothemodel]
•Prints the graphics data storedinthe print buffer in theprocessing of Function 112.
•Executes paper feeding correspondingtothenumber ofdotsinY directionofgraphics storedinthe print
buffer.
