Citizen CT-S280 - Page 414

- 413 -
●MSW3-3: Parallel 31 pin
[Outline] Printer canbereset byparallelI/F–31 Pinsignal. Select the handling ofthis signal.
OFF(0) ON(1)
Parallel31 pin Valid Invalid
ON(1) OPERATION: Used asreset signal
OFF (0) OPERATION:Not used asreset signal
●MSW3-4: Selecting paper
[Outline] Selects either thermal paper orblack markpaper.
OFF(0) ON(1)
Paper Select Thermal Black Mark
OperationatON(1):Sets black mark paper.
OperationatOFF(0):Sets thermalpaper.
●MSW3-5: Column Number
[Outline] Selects columnnumber.
OFF(0) ON(1)
ColumnNumber 48/32col 42/30col
OperationatON(1):Column number isset42/30columns
OperationatOFF(0):Column number isset48/32columns
●MSW3-6: Reserved [Fixed toOFF(0)]
●MSW3-7: CBM compatible mode
[Outline] Select enable/disable ofCBM compatible mode.
OFF(0) ON(1)
CBM Mode Invalid Valid
ON(1) OPERATION: Enable CBM compatible mode.
Controlcode <ESC~ J>becomes available.
OFF (0) OPERATION:CBMcompatible mode isdisabled.
