ComNav Commander P2 - Appendix 7 _______________________________________________________________________ 205; General Specifications; Table 18 - General Specifications

ComNav Commander P2 & P2VS Installation & Operation Appendices
Document PN 29010074 V4.1 - 205 -
Appendix 7
General Specifications
Parameter Specification
Dimensions
SPU 257 x 184 x 78 mm (10.1 x 7.3 x 3.1”)
Bracket Mount Head 157 x 118 x 73 mm (6.2 x 4.6 x 2.9”) @ 20° max tilt
– add 28 mm (1.1”) in width for bracket knobs
Surface Mount Head 156 x 113 x 24 mm (6.1 x 4.4 x 0.9”)
– add 11 mm (.43”) for Control Knob & 29 mm (1.1”) behind
surface to clear rear of Head (not incl. cable)
Flush-Mount Head 165 x 122 x 12 mm (6.5 x 4.8 x .47”)
– add 11 mm (.43”) for Control Knob & 41 mm (1.6”) behind
surface to clear rear of Head (not incl. cable)
Display
Monochrome Head Sunlight viewable high contrast QVGA (320x240), white LED
backlight
Colour Head Sunlight viewable high resolution QVGA (320x240) TFT display with
cold-cathode fluorescent backlight (400 Cd/m
2
typ.)
Operating Voltage 11 to 30 VDC
Power Consumption
SPU 200 mADC (all outputs off)
Control Head Monochrome: 80 mADC (max), Colour: 350 mADC (max)
Drive Output 20 Amps (max)
Navigational Interface
NAV1 input NMEA 0183 compliant, optically isolated, 4800 Baud
NAV2 input NMEA 0183 compliant, optically isolated, auto-baud detecting,
4800 & 9600 Baud
NMEA 0183 output Heading (10x per second) & Autopilot status (1x per second),
NMEA 0183 compliant, RS-422 compliant, RS-485 compliant,
4800 Baud, 8 data bits, no parity, one stop bit
Course Detection 0.1°
Course Resolution
AUTO
mode
1°
NAV
mode
0.1°
External Rudder Angle
Indicator
Supports up to five 500µA instruments
Jog Steering Control Input Yes
Rudder Follower Input 1.0 – 4.0 VDC centered at 2.5 VDC.
Control Head cable length
7.6 metres (25’) standard
Custom lengths up to 15 metres (50’) available
Table 18 – General Specifications
