ComNav Commander P2 - Dockside Setup Menu Parameters

ComNav Commander P2 & P2VS Installation & Operation Settings & Notes
Document PN 29010074 V4.1 - 219 -
Settings & Notes
Default & User Settings
Once your Commander P2 system has been installed and set up correctly, make a record of all the
settings for future reference, in the table below. ( Note: Default Value for P2VS is in bracket)
Parameter Range Default Value User Settings 1 User Settings 2
Dockside Setup Menu
Reset
press
F
F
n
n button to do n/a
Vessel type Displ, Semi, Plane, Stern, Sail Displ (Stern)
An. Compass Type
None, Mag, Flux, Fixed, Float,
HRS
None
Compass Setup
press
F
F
n
n button to do n/a
Drive Setup
press
F
F
n
n button to do n/a
Exit
press
F
F
n
n button to do n/a
Alarm O/P None, SW’D B-, SW’D B+ None
External Alarm Type All, Watch All
Thrust Type (CT7)
None, On/Off, Prop. None
Thrust MIN (CT7)
0 – 70% 0
Thrust MAX (CT7)
Thrust min to 100% 0
Language
English, Français, Español,
Íslenska, Italiano, Norsk
English
Standby Menu
Station Lock Lock, Unlock Unlock
Default Turn
U-Turn, Circle, M.O.B.,
Fishzag, Pre-Tack
U-Turn
Compass Source Analog, Digital, NAV1,NAV2 NAV1
Compass Cal
0 – 359° (for all types) Set at Runtime
Backlight Level 0 – 8 4
Contrast
0 – 8
(monochrome Control Heads)
4
Graphics
or
Display
Norm, Rev
(monochrome Control Heads)
Norm
A, B, C
(colour Control Heads)
A
Watch Alarm Off, 1 – 30 sec Off
Fishzag time 30 – 300 sec 60
Battery
Read only value n/a
