Page #104 background image
D-Link DWC-1000 User Manual 104
Section 4 - Advanced WLAN Conguration
3. Enter the new primary address, new backup address, and AP Prole.
4. Click Save.
Field Description
MAC Address MAC address of the access point.
IP Address IP address of the access point.
Time Since Last Update Time since any information has been received from this access point.
Primary IP Address The IP address of the primary provisioned switch as reported by the AP.
Backup IP Address The IP address of the backup provisioned switch as reported by the AP.
Mutual Authentication Mode Shows whether the Mutual Authentication mode is currently enabled.
Unmanaged AP Reprovisioning
Mode
The congured re‐provisioning mode in the AP, which is one of the following:
Enable - The AP can be reprovisioned when it is not managed.
Disable - The AP cannot be reprovisioned when it is not managed.
AP Provisioning Status
Status of the most recently issued AP provisioning command, which is one of the
following:
Not Started - Provisioning has not been done for this AP.
Success - Provisioning nished successfully for this wireless controller. The AP
Provisioning Status Table should reect the latest provisioning conguration.
In Progress - Provisioning is executing for this AP.
Invalid Switch IP Address - Either primary or backup wireless controller IP
address is not in the cluster or the mutual authentication mode is enabled and
the primary wireless controller IP address is not specied.
Provisioning Rejected - AP is not managed and is congured not to accept
provisioning data in unmanaged mode.
Timed Out - The last provisioning request timed out.
AP Certicate and Prole Trans-
mit Status
Status of the last AP prole and X.509 Certicate distribution to the Primary and
Backup switches. This status is changed as a result of the AP provisioning command.
The X.509 certicate is sent to the primary and backup switches only if mutual
authentication is enabled. The status is one of the following:
Not Started - No information for this AP has been sent to the primary and
backup switch.
Success - AP Prole and X.509 Certicate is sent to Primary and Backup Switches.
Failed - The primary or backup switch wasn’t in the cluster when this switch
attempted to send the information.
New Primary IP Address Enter the IP address of the wireless controller that should manage the AP.
New Backup IP Address
Enter the IP address of switch to which the AP should try to connect, if it is unable to
connect to the primary wireless controller.
Prole Select an AP prole you want to use.
