D-Link DWC-1000 User Manual 222
Section 6 - Securing Your Network
Congure POP3 Server
Path: Security > Authentication > External Auth Server > POP3 Server
POP3 is an application layer protocol most commonly used for e-mail over a TCP/IP connection. The authentication
server can be used with SSL encryption over port 995 to send encrypted trac to the POP3 server. The POP3
servers certicate is veried by a user-uploaded CA certicate. If SSL encryption is not used, port 110 will be used
for the POP3 authentication trac.
The wireless controller acts only as a POP3 client to authenticate a user by contacting an external POP3 server.
This authentication option is available for IPSec, PPTP/L2TP Server and Captive Portal users. Note that POP3 for
PPTP / L2TP servers is supported only with PAP and not with CHAP / MSCHAP / MSCHAPv2 encryption.
To congure your POP3 Server:
1. Go to Security > Authentication > External Auth Server > POP3 Server tab.
2. Complete the elds in the table below and click Save.
Field Description
Authentication Server IP address of the POP3 authentication server.
Authentication Port RADIUS authentication server port to send POP3 messages.
SSL Enable
Enable SSL support for POP3. If this option is enabled, it is mandatory to select a
certicate authority for it.
CA File Certicate Authority to verify POP3 server’s certicate.
Timeout
Set the amount of time in seconds, the controller should wait for a response from
the POP3 server.
Retries
This determines the number of tries the controller will make to the POP3 server
before giving up.
