D-Link DWC-1000

D-Link DWC-1000 User Manual 331
Section 8 - Viewing Status and Statistics
Path: Status > Wireless Information > WDS Groups Status > WDS Link Statistics
The WDS Group Link Statistics page displays summary information about the packets sent and received on the
WDS links.
Field Description
ID The group number that identies the congured WDS AP group.
Source AP MAC The MAC address of one end-point of the WDS link.
Source Radio The radio number of the WDS link endpoint on the source AP.
Destination AP MAC The MAC address of the Source AP in the group.
Destination Radio The radio number of the WDS link endpoint on the destination AP.
Source AP Packets/ Bytes Sent Number of packets/bytes sent by the source AP.
Source AP Packets/Bytes Received Number of packets/bytes received by the source AP.
Destination AP Packets/Bytes Sent Number of packets/bytes sent by the destination AP.
Destination AP Packets/Bytes Received Number of packets/bytes received by the destination AP.
Viewing WDS Link Statistics
