D-Link DWC-1000 User Manual 203
Section 6 - Securing Your Network
Editing Users
Path: Security > Authentication > User Database > Users
There may be times when you need to edit a user. For example, you might want to change the users login
password or idle timeout.
To edit a user:
1. Click Security > Authentication > User Database > Users tab. The Users List page will appear.
2. Right-click on the user you want to edit, and click Edit.
3. Complete the elds given in the table below, and click Save.
Field Description
User Name
Enter a unique name for this user. The name should allow you to easily identify this user
from others you may add.
First Name Enter the rst name of the user.
Last Name Enter the last name of the user.
Select Group Select the group to which this user will belong.
Edit Password
Toggle this option to enter the password to be used by this user to log in to the web
management interface.
Current Logged in
Administrator Password
Enter the current case-sensitive login password. For security, each typed password
character is masked with a dot (•).
New Password
Enter the new case-sensitive login password. For security, each typed password
character is masked with a dot (•). Record the new password in Appendix A.
Conrm Password Enter the new password again.
