D-Link DWC-1000 User Manual 311
Section 8 - Viewing Status and Statistics
Path: Status > Wireless Information > Access Point > RF Scan
The radio(s) on each access point can scan the radio frequency periodically to collect information about
other access points and wireless clients that are within range. In normal operating mode, the access point
always scans on the operational channel for the radio. The RF Scan page shows information about other
access points and wireless clients that the wireless controller has detected. Right-click on an AP or client to
bring up options to view details.
Fields on the AP Authentication Failure Status Page:
Field Description
MAC Address
Ethernet address of the AP. If the MAC address of the access point is followed
by an asterisk (*), it was reported by a peer controller.
IP Address IP address of the access point.
Last Failure Type
Last type of failure that occurred. Possible values are:
Local Authentication
No Database Entry
Not Managed
RADIUS Authentication
RADIUS Challenged
RADIUS Unreachable
Invalid RADIUS Response
Invalid Prole ID
Prole Mismatch-Hardware Type
Age Time since failure occurred.
RF Scan
