D-Link DWC-1000 User Manual 298
Section 8 - Viewing Status and Statistics
Wireless Information
Viewing Controller Status and Statistics
Path: Status > Wireless Information > Controller Status
This page shows the status and statistics information about the controller.
Field Description
WLAN Controller Operational Status This status eld displays the operational status of the WLAN controller.
IP Address The IP address of the wireless controller.
Peer Controllers The number of peer WLAN controllers detected on the network.
Cluster Controller
Indicates whether this controller is the Cluster Controller for the cluster. Among
a group of peer Controllers, one of the Controllers is automatically elected or
congured to be the Cluster Controller. The Cluster Controller gathers status
and statistics about all APs and clients in the peer group.
Note: Only the Cluster Controller controller can display managed APs, clients,
statistics, and RF Scan databases for the whole cluster. The Controllers that are not
Cluster Controllers can display information only about locally attached devices.
Cluster Controller IP Address The IP address of the peer controller that is the Cluster Controller.
