D-Link DWC-1000 User Manual 168
Section 5 - Advanced Network Conguration
IP Aliasing
Path: Network > Internet (IPv4) > IP Aliasing
A single Option Ethernet port can be accessed via multiple IP addresses by adding an alias to the port. This is
done by conguring an IP Alias address. To edit or delete any existing aliases, right-click the alias and select either
Edit or Delete.
Field Description
Interface Select either Option1 or Option2.
IP Address Enter an alias IP address for the Option interface you selected.
Subnet Mask Enter a subnet mask for the Option interface you selected.
Save Click save to activate your settings.
To create a new alias:
1. Click Network > Internet (IPv4) > IP Aliasing.
2. Click Add New IP Aliasing.
3. Enter the following information, and click Save.
