D-Link DWC-1000 User Manual 263
Section 7 - VPN
Client
Path: VPN > PPTP VPN > Client
PPTP VPN Client can be congured on this switch. Using this client, you can access remote network which is
local to PPTP server. Once client is enabled, the user can access Status > Active VPNs page and establish PPTP
VPN tunnel by clicking Connect.
Field Description
Client Toggle to ON to enable PPTP client.
Server IP Enter the IP address of the PPTP server you want to connect to.
Remote Network Enter the remote network address. This address is local for the PPTP Server.
Remote Netmask Enter the remote network subnet mask.
Username Enter your PPTP user name.
Password Enter your PPTP password.
MPPE Encryption Toggle to ON to enable Microsoft Point-to-Point Encryption (MPPE).
Idle Time Out Enter the amount of time (in seconds) that you will disconnect from the PPTP server when idle.
Save Click Save to save and activate your settings.
To congure the switch as a PPTP VPN client:
1. Click VPN > PPTP VPN > Client tab.
2. Toggle Client to ON and complete the elds in the table below.
