Page #180 background image
D-Link DWC-1000 User Manual 180
Section 5 - Advanced Network Conguration
3. Complete the elds given in the table below, and click Save.
Field Description
Route Name
Enter a unique name for this static route. The name should allow you to easily identify
this static route from others you may add.
Active
Activates or deactivates the status route. Choices are:
ON = activate static route.
OFF = deactivate static route.
Private
Designates the static route as private. Choices are:
ON = static route is private.
OFF = static route is not private.
IPv6 Destination The wireless controller will lead to this destination host or IP address.
IPv6 Prex Length The number of prex bits in the IPv6 address that dene the subnet.
Interface
Select the wireless controller interface that will interface to the static route. Choices are:
Option 1/ Option 2 = the wireless controller’s Option port will interface to the static
route.
LAN = the wireless controller’s LAN or VLAN port will interface to the static route.
Sit0 Tunnel
IPv6 Gateway
IP Address of the gateway through which the destination host or network can be
reached.
Metric
Determines the priority of the route. If multiple routes to the same destination exist, the
route with the lowest metric is chosen.
Editing/Deleting Static Routes
After you add static routes, you can edit it if you need to change settings. To edit a static route, right-click the
static route you want to edit, and click Edit.
To delete a static route, right-click the static route you want to remove, and click Delete.
