D-Link DWC-1000 User Manual 321
Section 8 - Viewing Status and Statistics
Path: Status > Wireless Information > Associated Clients > Ad Hoc Clients
An ad hoc client is a wireless client that gains access to the WLAN through a wireless client that is associated with
an access point. The ad hoc client does not communicate directly with the AP. Ad hoc networks are a particular
concern because they consume RF bandwidth and can present a security risk.
Right-click Commands on the WLAN Associated Ad Hoc Clients List
Field Description
MAC Address
The Ethernet address of the client. If the Detection Mode is Beacon then the
client is represented as an AP in the RF Scan database and the Neighbor AP
List. If the Detection Mode is Data Frame then the client information is in the
Neighbor Client List.
AP MAC Address The base Ethernet MAC Address of the managed AP which detected the client.
Location The congured descriptive location for the managed AP.
Radio The radio interface and its congured mode that detected the ad hoc device.
Detection Mode
The mechanism of detecting this Ad Hoc device. The possible values are
Beacon Frame or Data Frame.
Age Time since last detection of the ad hoc network.
Field Description
Delete All
Deletes all ad hoc client entries from the list. Clearing the list does not
disassociate any of the ad hoc clients, and the clients might still be involved in
the ad hoc network.
Deny
Blocks an ad hoc client from WLAN access. The MAC address is added to the
Known Client database where the default action is Deny.
Allow
Allows an ad hoc client access to the WLAN. The MAC address is added to the
Known Client database where the default action is Allow.
Ad Hoc Clients

Table of Contents

Other manuals for D-Link DWC-1000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWC-1000 and is the answer not in the manual?

D-Link DWC-1000 Specifications

General IconGeneral
Ethernet LANYes
Wi-Fi standards802.11a, 802.11b, 802.11g
Networking standardsIEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)6
Security algorithms3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
CertificationFCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in displayNo
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Power requirementsDC 12V/2.5A
Power consumption (typical)19.3 W
Pallet width1200 mm
Pallet length1100 mm
Pallet height (air)1419 mm
Pallet height (sea)1847 mm
Pallet gross weight (air)415236 g
Pallet gross weight (sea)545648 g
Quantity per pallet (air)144 pc(s)
Quantity per pallet (sea)192 pc(s)
Shipping (inner) case width296 mm
Shipping (inner) case height428 mm
Shipping (inner) case length354 mm
Shipping (inner) case weight10826 g
Shipping (inner) case net weight10016 g
Number of cartons per pallet (air)36 pc(s)
Number of cartons per pallet (sea)48 pc(s)
Quantity per shipping (inner) case4 pc(s)
Weight and Dimensions IconWeight and Dimensions
Package depth396 mm
Package width273 mm
Package height80 mm
Package weight2504 g
Dimensions (WxDxH)280 x 180 x 44 mm
