D-Link DWC-1000 User Manual 128
Section 4 - Advanced WLAN Conguration
Peer Group
The Peer Group Conguration feature allows you to send a variety of conguration information from one
wireless controller to all other wireless controllers. In addition to keeping the wireless controller synchronized,
this function allows you to manage all wireless controllers in the cluster from one controller.
Congure Peer Group
Path: Wireless > Peer Group > Peer Conguration
You can copy portions of the wireless controller conguration from one controller to another controller in the
cluster. The Peer Group Conguration Enable/Disable page allows you to select which parts of the conguration
to copy to one or more peer wireless controllers in the group.
You can make changes to a conguration that has been sent to one or more peer controllers, and you can make
changes to a conguration received from a peer controller. No changes automatically propagate from one
controller to the cluster; you must manually initiate a request on one controller in order to copy any conguration
to its peers.
1. Click Wireless > Peer Group > Peer Conguration.
2. Toggle each option to On or O, and then click Save. Refer to the table below and on the next page.
Field Description
General
Enable this eld to include the basic and advanced global settings in the conguration
that the controller pushes to its peers. The conguration does not include the
controller IP address since that is a unique setting.
Discovery
Enable this eld to include the L2 and L3 discovery information, including the VLAN
list and IP list, in the conguration that the controller pushes to its peers.
Channel / Power
Enable this eld to include the RF management information in the conguration that
the controller pushes to its peers.
AP Database
Enable this eld to include the AP Database (Valid AP) in the conguration that the
controller pushes to its peers.
