D-Link DWC-1000 User Manual 309
Section 8 - Viewing Status and Statistics
Path: Status > Wireless Information > Access Point > Peer Managed
The Peer Controller Managed APs List page provides information about the access points that each peer controller
in the cluster manages. Each peer controller is identied by its IP address.
Peer Managed
Field Description
MAC Address MAC address of each access point managed by the peer controller.
AP IP Address IP address of the access point.
Peer IP Address
IP address of the peer controller that manages the access point. This eld
appears when All is selected from the drop-down menu.
Location Descriptive location congured for the managed access point.
Prole Access point prole that the wireless controller applies to the access point.
Hardware ID Hardware ID associated with the access point hardware platform.
