D-Link DWC-1000 User Manual 308
Section 8 - Viewing Status and Statistics
Button Description
AP Details Shows detailed status information collected from the access point.
Radio Details Shows detailed status for a radio interface.
Neighbor APs
Shows the neighbor APs that the specied AP has discovered through periodic
RF scans on the selected radio interface.
Neighbor Clients
Shows information about wireless clients associated with an access point or
detected by the access point radio.
VAP Details
Shows summary information about the virtual access points (VAPs) for the
selected access point and the access point radio interface that the wireless
controller manages.
Distributed Tunnel Shows information about the L2 tunnels currently in use on the access point.
Reset AP Reset the managed AP back to the factory default settings.
Disassociate Clients View disassociate clients with the selected AP.
The Managed AP Statistics page shows information about trac on the access point’s wired and wireless
interfaces. This information can help diagnose network issues, such as throughput problems. To view the
statistics for a managed access point, right-click on its entry in the Managed AP List and select AP Statistics,
Radio Statistics, and VAP Statistics.
Button Description
AP Statistics
Shows the number and type of packets transmitted and received on a specic
access point.
Radio Statistics
Shows per-radio information about the number and type of packets
transmitted and received for a specic access point.
VAP Statistics
Shows per-VAP information about the number of packets transmitted and
received and the number of wireless client failures for a specic access point.
