D-Link DWC-1000 User Manual 314
Section 8 - Viewing Status and Statistics
Path: Status > Wireless Information > Access Point > Hardware Capability
The wireless controller supports access points that have dierent hardware capabilities, such as number of
radios, supported IEEE 802.11 modes, and software images. Using the AP Hardware Capability page, you view
information about the radio hardware and IEEE modes supported by access points, as well as software images
that are available for download to the access point.
The right-click option will display the radio Information for the selected hardware type.
Field Description
Hardware Type
Shows the ID number assigned to each access point hardware type. The
wireless controller supports six dierent types of access point hardware.
Hardware Type Description Describes the platform and the supported IEEE 802.11 modes.
Radio Count Shows whether the hardware supports one radio or two radios.
Image Type Shows the type of software the hardware requires.
Hardware Capability
