Section 4 - Advanced WLAN Conguration
Field Description
IP ACL
Select a type of ACL to create, or select an existing ACL to delete from the dropdown
menu. You can create the following types of IP ACLs:
• Standard IP ACL: Allows you to permit or deny trac from a source IP address.
• Extended IP ACL: Allows you to permit or deny specic types of layer 3 or layer
4 trac from a source IP address to a destination IP address. This types of ACL
provides more granularity and ltering capabilities than the standard IP ACL.
• Named IP ACL: Allows you to create an Extended IP ACL that is identied by a
name rather than a number. These ACLs have the same capabilities as Extended
IP ACLs with respect to match criteria and actions supported.
IP ACL ID
Enter an ID number for the ACL to congure. This eld appears if you select Create
Standard IP ACL or Create Extended IP ACL from the IP ACL dropdown menu. For a
Standard IP ACL, the acceptable ID values are 1-99. From an Extended IP ACL, the
acceptable ID values are 101-199.
IP ACL Name
This eld appears if you select Create New Named IP ACL from IP ACL dropdown
menu. Specify an IP ACL Name string which includes only alphanumeric characters.
The name must start with an alphanumeric character. This eld will display the name
of the currently selected IP ACL if the ACL has already been created.
IP ACL Rules
Path: Wireless > ACL > IP ACL Rules
This opens IP ACL Rule Conguration page. Use this page to congure the rules for the IP Access Control Lists.
The elds present on this page depend on whether you select a standard, extended, or named IP ACL from the
IP ACL eld, and whether the rule action is permit or deny. A Standard/Extended IP ACL must rst be selected to
congure rules. The rule identication, and the ‘Action’ and ‘Match Every’ parameters must be specied next. If
‘Match Every’ is set to False, more options will be present from which the match criteria can be congured.
