Section 4 - Advanced WLAN Conguration
Field Description
• TOS Mask: This value is a hexadecimal number from 00 to FF. Species the bit
positions that are used for comparison against the IP TOS eld in a packet.
IP ACL Conguration Example
Example: To block ICMP trac between the two wireless clients, say STA1 (Station 1) and STA2 (Station 2).
The topology for the above conguration is given below:
Follow the steps given below:
1. Go to Wireless > ACL > IP ACL page, and click Add New IP ACL.
2. Select IP ACL as Create New Extended IP ACL from the drop-down menu.
3. Enter IP ACL ID.
