D-Link DWC-1000 User Manual 146

Section 5 - Advanced Network Conguration

Field Description

Status

Enable or disable the RADVD process here to allow stateless auto conguration of the

IPv6 LAN network.

Advertise Mode

Two Advertise Modes:

• Unsolicited Multicast: Select to send router advertisements (RA’s) to all the

interfaces belonging to the multicast group.

• Unicast Only: This option restricts advertisements to well known IPv6 addresses

only (RA’s are sent to the interface belonging to the known address only).

Advertise Interval

If Advertise Mode = Unsolicited Multicast, this sets the maximum advertise interval. The

advertise interval used when RADVD is enabled is a random value between Minimum

Router Advertisement Interval and Maximum Router Advertisement Interval. The

minimum router advertisement interval is 1/3 of this congured value, and the default

is 30 seconds.

RA Flags

The router advertisements (RA’s) can be sent with one or both of these ags: Managed

and Other. Choose Managed to use the administered /stateful protocol for address

auto conguration. If the Other ag is selected, the host uses administered/stateful

protocol for non-address auto conguration.

Router Preference

Choose between Low/Medium/High for the preference associated with the RADVD

process of the controller. This feature is useful if there are other RADVD enabled devices

on the LAN. The default is high.

MTU

This is used in RA’s to ensure all nodes on the network use the same MTU value in the

cases where the LAN MTU is not well known. The default is 1500

Router Lifetime The lifetime in seconds of the route. The default is 3600 seconds.
