Page #178 background image
D-Link DWC-1000 User Manual 178
Section 5 - Advanced Network Conguration
Field Description
Route Name
Enter a unique name for this static route. The name should allow you to easily identify
this static route from others you may add.
Active
Activates or deactivates the status route. Choices are:
ON = activate static route.
OFF = deactivate static route.
Private
Designates the static route as private. Choices are:
ON = static route is private.
OFF = static route is not private.
Destination IP Address Enter the IP address of the static routes destination.
IP Subnet Mask Enter the subnet mask of the static route.
Interface
Select the wireless controller interface that will interface to the static route. Choices are:
Option 1/ Option 2: The wireless controller’s Option port will interface to the static
route.
LAN > VLAN: The wireless controllers LAN or VLAN port will interface to the static
route.
DMZ: The port congured for DMZ will interface to the static route.
Gateway IP Address
Enter the IP address of the gateway router, which is the next hop address for the wireless
controller.
Metric Enter the administrative distance of the route. The range is 2 to 15.
