D-Link DWC-1000 User Manual 185
Section 5 - Advanced Network Conguration
Field Description
OSPFv3 Enable Toggle ON to enable OSPFv3.
Interface Displays the physical network interface on which OSPFv3 is Enabled/Disabled.
Priority
Helps to determine the OSPFv3 designated controller for a network. The controller with the
highest priority will be more eligible to become Designated Controller. Setting the value to
0 makes the controller ineligible to become Designated Controller. The default value is 1.
Lower the value means higher the priority.
Hello Interval
The number of seconds for Hello Interval timer value. Enter the number in seconds that
the Hello packet will be sent. This value must be the same for all controllers attached to a
common network. The default value is 10 seconds.
Dead Interval
The number of seconds that a device’s hello packets must not have been seen before its
neighbors declare the OSPF controller down. This value must be the same for all controllers
attached to a common network. The default value is 40 seconds. OSPF requires these
intervals to be exactly the same between two neighbors. If any of these intervals are
dierent, these controllers will not become neighbors on a particular segment.
Cost Enter the cost of sending a packet on an OSPFv3 interface.
Save Click Save to save your settings.
