D-Link DWC-1000 User Manual

D-Link DWC-1000 User Manual 214
Section 6 - Securing Your Network
Field Description
General Details
Prole Name
Enter a name for this captive portal prole. The name should allow you to dierentiate this
captive prole from others you may set up.
Browser Title Enter the text that will appear in the title of the browser during the captive portal session.
Background
Select whether the login page displayed during the captive portal session will show an image
or color. Choices are:
• Image = displays an image as the background on the page. Use the Page Background
Image eld to select a background image.
• Color = sets the background color on the page. Select the color from the drop-down
menu
Page Background
If you set Background to Image, upload the image le by clicking Add > Browse. Select an
image, click Open and then click the Upload button. The maximum size of the image is 100 kb.
Page Background
Upload
Choose the le you want to upload.
Page Background
Color
If you set Background to Color, select the background color of the page that will appear during
the captive portal session from the drop-down menu.
Custom Color If you choose Custom on Page Background Color, enter the HTML color code.
Header Details
Background
Select whether the login page displayed during the captive portal session will show an image
or color. Choices are:
• Image = show image on the page. Use the Header Background Color eld to select a
background color. The maximum size of the image is 100 kb.
• Color = show background color on the page. Use the radio buttons to select an image.
Header Background
If you set Background to Image, upload the image le by clicking Add > Browse. Select an
image, click Open and then click the Upload button. The maximum size of the image is 100 kb.
Header Background
Upload
Choose the le you want to upload.
Header Background
Color
If you set Background to Color, select the header color from the drop-down menu.
Custom Color
If you choose Custom on Page Background Color, you can choose particular color by lling in
the HTML color code.
Header Caption Enter the text that appears in the header of the login page during the captive portal session.
Caption Font Select the font for the header text.
Font Size Select the font size for the header text.
Font Color Select the font color for the header text.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
