D-Link DWC-1000 User Manual 247
Section 8 - Security
3. Complete the elds from the table below and click Save.
Field Description
Name Enter a name for your rule.
Enable Toggle to ON to activate the rule.
Protocol Select TCP or UDP.
Interface Select either LAN or DMZ.
Outgoing (Trigger) Port
Range
Enter the start and end trigger port range.
Incoming Port Range Enter the port range to open.
Save Click to save your settings.
4. Click on the Application Rules Status tab to see a list of rules and their status.

Table of Contents

Other manuals for D-Link DWC-1000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWC-1000 and is the answer not in the manual?

D-Link DWC-1000 Specifications

General IconGeneral
Ethernet LANYes
Wi-Fi standards802.11a, 802.11b, 802.11g
Networking standardsIEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)6
Security algorithms3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
CertificationFCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in displayNo
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Power requirementsDC 12V/2.5A
Power consumption (typical)19.3 W
Pallet width1200 mm
Pallet length1100 mm
Pallet height (air)1419 mm
Pallet height (sea)1847 mm
Pallet gross weight (air)415236 g
Pallet gross weight (sea)545648 g
Quantity per pallet (air)144 pc(s)
Quantity per pallet (sea)192 pc(s)
Shipping (inner) case width296 mm
Shipping (inner) case height428 mm
Shipping (inner) case length354 mm
Shipping (inner) case weight10826 g
Shipping (inner) case net weight10016 g
Number of cartons per pallet (air)36 pc(s)
Number of cartons per pallet (sea)48 pc(s)
Quantity per shipping (inner) case4 pc(s)
Weight and Dimensions IconWeight and Dimensions
Package depth396 mm
Package width273 mm
Package height80 mm
Package weight2504 g
Dimensions (WxDxH)280 x 180 x 44 mm
