D-Link DWC-1000 User Manual 270
Section 7 - VPN
Field Description
Portal Layout Name
Enter a name for this portal. This name will be used as part of the path for the SSL portal
URL. Only alphanumeric characters are allowed for this eld.
Login Prole View Select a login prole from the drop-down menu.
Portal Site Title
Enter the portal web browser window title that appears when the client accesses this
portal. This eld is optional.
Banner Title The banner title that is displayed to SSL VPN clients prior to login. This eld is optional.
Banner Message Enter a message you want to display.
Display Banner Message on
Login Page
Toggle to ON to display the banner title and message or OFF to hide the banner title
and message.
HTTP Meta Tags for Cache
Control
Toggle to ON or OFF. This security feature prevents expired web pages and data from
being stored in the client‘s web browser cache. It is recommended to toggle to ON.
Active X Web Cache Cleaner
Toggle to ON or O. An ActiveX cache control web cleaner can be pushed from the
gateway to the client browser whenever users login to this SSL VPN portal.
Authentication Type Select the type of authentication from the drop-down menu.
Group Select what group to include from the drop-down menu.
VPN Tunnel Page Toggle to ON to allow remote users to view this page.
Port Forwarding Toggle to ON to allow remote users to view this page.
Save Click to save your settings.
