Section 7 - VPN
Field Description
Mode Select Server.
VPN Network Enter the IP network for the VPN.
VPN Netmask Enter the netmask.
Duplicate CN
This feature allows multiple clients with the same common name to concurrently connect.
Duplicate CN option can be congured on server side. If we enable this option, we will be able
to use same certicate to connect for multiple clients. For this feature, user based authentication
is also required and multiple clients require to have their respective user-name and password.
Port Enter what port to use. The default port is 1194.
Tunnel Protocol Select either TCP or UDP.
Encryption Algo-
rithm
Select the encryption algorithm from the drop-down menu.
Hash Algorithm Select the hash algorithm from the drop-down menu.
Tunnel Type
Select either Full Tunnel or Split Tunnel. Full Tunnel mode just sends all trac from the client
across the VPN tunnel to the controller. Split Tunnel mode only sends trac to the private LAN
based on pre-specied client routes. If you select Split Tunnel, refer to “LAN Conguration” on
page 137 to create local networks.
Certicates
Select the set of certicates openvpn server uses. First Row: Set of certicates and keys the
server uses. Second Row: Set of certicates and keys newly uploaded.
Enable Tls Authenti-
cation Key
Enabling this adds Tls authentication which adds an additional layer of authentication. Can be
checked only when the tls key is uploaded. Disabled by default.
Block Invalid Client
Certicates
Enabling this adds facility to block invalid client certicate. This feature requires crl certicate
which contains list of client certicates to be blocked. Please upload crl certicate in OpenVPN
Authentication page.
Allow only User
Based Auth Congu-
ration
This method does not require the client certicate, client will authenticate using the username/
password only.
User Based Auth
Conguration
This option is introduced to provide the additional authentication method using username/
password.
Authentication
Server
Shows the available authentication servers among which one can be selected for openvpn. All
users login into the OmniSSL portal for this openvpn are authenticated through the selected
server. Available authentication servers are 1)Local User Database 2)Radius Server 3)LDAP
Server 4)POP3 5)Active Directory 6)NT Domain
Authentication Type
This option is only congurable when authentication server is selected as Radius Server. The
available authentication types are PAP/CHAP/MSCHAP/MSCHAPV2.
Save Click Save to save and activate your settings.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
