D-Link DWC-1000 User Manual

D-Link DWC-1000 User Manual 286
Section Description
Memory AP Status (X/Y)
Graphical representation of total APs in connected, disconnected, and
Connection failure state.
(X/Y) X: represents number of AP managed by controller. Y: represents number
of total AP supported by the controller, based on the licenses installed.
Click on Details to get a list of APs with Model Name, Firmware, MAC Address,
IP Address, Location, Status, and System UpTime.
Top 5 AP Utilization
Graphical representation of Top 5 AP Utilization based on the individual WLAN
trac.
WLAN Trac shows the MB trac consumption of AP. RF Utilization shows
RF Utilization percentage (2.4 GHz and 5 GHz) of AP. Authenticated Clients
show associated clients to AP.
Click on Details to get detailed AP Statistics including Model Name, IP Address,
Location, MAC Address, Firmware, AP Up Time, Auth. Clients, WLAN Trac, RF
Utilization 5G, and RF Utilization 2.4G
Controller Memory Utilization
Graphical representation of total memory utilization. Click on Details to get
detailed numbers of Total Memory, Used Memory, Free Memory, Cached
Memory, Buer Memory in MBs.
Top 5 Client Trac
Graphical representation of Top 5 Client based on the individual WLAN trac.
Click on Details to get detailed Client Statistics including Client IP Address,
Client MAC Address, SSID, AP MAC Address, AP Location, Channel, NetBIOS, Rx
Trac (MB), and Tx Trac (MB)
Controller CPU Utilization
Percent of the CPU utilization currently consumed by the device. The CPU
utilization is broken down into specics such as all user space processes, such
as management operations, kernel space processes, and CPU idle time or IO.
Users Info
Graphical representation of total connected clients of dierent groups.
Click on Details to get detailed counts of Admin Users Logged in, Guest Uses
Logged in, Captive Portal uses Logged in, Front Desk Users Logged in, SSLVPN
Users Logged in, PPTP Users Logged in, and L2TP Users Logged in.
Trac Overview
Graphical representation of trac generated using these protocols http,
email, IPsec, https. Click on Details to get detailed trac in KB for dierent
protocols such as HTTP, HTTPs, DNS, IMAP2, IMAP3, NFS, POP3, SMTP, SNMP,
SSH, and TELNET of all interfaces.
Bandwidth Usage
Displays bandwidth usage by network segment such as WLAN or LAN. The
data is broken into by applications service such as HTTP, HTTPS, DNS, SNMP,
and others.
VPN’s
Displays the current number of concurrent and active IPsec and SSL VPN
sessions.
Trac Information
Displays a grid of trac statistics (incoming, outgoing, dropped in and
dropped out packets) for each interface.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
