Section 8 - Viewing Status and Statistics
Section Description
LAN
Incoming Packets The number of IP packets entering the port.
Outgoing Packets The number of packets leaving the port.
Dropped In Packets Packets dropped on the inbound path of the interface.
Dropped Out Packets Packets dropped on the outbound path of the interface.
VLAN
Port The port that the VLAN is associated with.
Incoming Packets The number of IP packets entering the port.
Outgoing Packets The number of packets leaving the port.
Dropped In Packets Packets dropped on the inbound path of the interface.
Dropped Out Packets Packets dropped on the outbound path of the interface.
WLAN Info
Transmitted Total packets transmitted across all APs managed by the controller.
Received Total packets received across all APs managed by the controller.
Transmit Dropped
Total packets transmitted across all APs managed by the controller that were
dropped.
Receive Dropped Packets dropped on the inbound path of the interface.
Active Info
ICMP Received Displays the total number of ICMP packets received on the interface.
Active VPN Tunnels
Displays the current number of concurrent and active IPsec and SSL VPN
sessions.
Available VLANs Displays the current number of enabled and active VLAN interfaces.
Active Interfaces Displays the number of enabled interfaces.
Count Displays the count for number of packets.

D-Link DWC-1000 Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Networking standards	IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Number of managed Wi-Fi Access Points (max)	6
Security algorithms	3DES, DES, WEP, WPA, WPA2
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Certification	FCC B, CE B, VCCI, C-tick, IC, cUL, LVD (EN60950-1)
Built-in display	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Power requirements	DC 12V/2.5A
Power consumption (typical)	19.3 W
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1419 mm
Pallet height (sea)	1847 mm
Pallet gross weight (air)	415236 g
Pallet gross weight (sea)	545648 g
Quantity per pallet (air)	144 pc(s)
Quantity per pallet (sea)	192 pc(s)
Shipping (inner) case width	296 mm
Shipping (inner) case height	428 mm
Shipping (inner) case length	354 mm
Shipping (inner) case weight	10826 g
Shipping (inner) case net weight	10016 g
Number of cartons per pallet (air)	36 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Package depth	396 mm
Package width	273 mm
Package height	80 mm
Package weight	2504 g
Dimensions (WxDxH)	280 x 180 x 44 mm
