D-Link DWC-1000 User Manual 64
Section 4 - Advanced WLAN Conguration
5. Fill-in the elds given in the table below.
Field Description
Manual Power Adjustments
Current Status
Shows the Current Status of the plan, which is one of the following states:
None: The power adjustment algorithm has not been manually running since
the last controller reboot.
Algorithm In Progress: The power adjustment algorithm is running.
Algorithm Complete: The power adjustment algorithm has nished running.
A table displays to indicate proposed power adjustments. Each entry shows the
AP along with the current and new power levels.
Apply In Progress: The controller is adjusting the power levels that the APs use.
Apply Complete: The algorithm and power adjustment are complete.
Manual Power Adjustments List
AP MAC address Identies the AP MAC address.
Location Identies the location of the AP, which is set in the Valid AP database.
Radio Interface Identies the radio.
Current Power Shows the earlier power level for the AP.
New Power Shows the proposed power level for the AP.
