Danfoss Turbocor TTS Series User Manual

126 of 282 M-SV-001-EN Rev. G
Figure 4-130 Soft Start AC/DC Harness Connections - TTS/TGS/TTH/TGH (Except TTS300/TGS230)
J1 High Voltage AC/
DC Connector
J1 Connector
J4 Connector
L1, L2, and L3
Spade Terminals
(3 places)
J7: DC-DC Trigger
Signal Connector
DC+ and DC -
Spade Terminals
For use with potted DC-DC
For use with Rev. H compressors
L1, L2, and L3 Ring
Terminals (3 places)
DC+ and DC -
Spade Terminals
J1 Connector
J8 DC Link J1 AC Inputs
