264 of 282 M-SV-001-EN Rev. G
6.2 Moisture Prevention Measures
6.2.1 Required Items
This section applies to all TTS/TGS/TTH/TGH compressors.
The following steps are recommended to prevent condensate infiltration and stagnation in the
electrical connections. Condensation issues may become exaggerated in hot and humid conditions.
Consumables:
• Lint-free cloth or clean rags
• Soft-bristle brush
• Small wire brush
• Greaseless lubricant spray
• Rust inhibitor spray
• Dielectric grease (Danfoss LLC part # 901982 or equivalent)
• Dielectric grease spray
Application of Dielectric Grease
The dielectric grease can be applied by:
• Finger
• Small brush
6.2.1.1 Service Side Disassembly
1. Isolate the compressor power as described in Section "1.8 Electrical Isolation" on page 19 of
this manual.
2. Allow time for the compressor to reach ambient temperature.
3. Remove the Service Side Cover from the compressor.
4. Remove the I/O Cable, Serial Driver, BMCC, and PWM from the Backplane Board. Make sure the
board assemblies do not come in contact with electric or static sources.
Figure 6-1 Module Removal
NOTE
The Danfoss LLC part # 901982 Dielectric Grease is a natural lanolin-based product which is non-toxic.
• • • DANGER • • •
Be sure to follow the manufacturer’s usage and safety recommendations when using the aforementioned chemicals.
Motor Cooling
Valve Solenoids
I/O Cable
Serial Driver
BMCC
PWM
To Next Page
