Danfoss Turbocor TTS Series User Manual

206 of 282 M-SV-001-EN Rev. G
Figure 4-262 Potted DC-DC - Top View
Figure 4-263 Open Frame DC-DC - Top View
6. Connect the DC-DC cables.
7. Install the Soft Start. Refer to "4.15.3 Soft Start Removal and Installation" on page 112.
8. Install the top covers. Refer to "4.2 Compressor Covers" on page 56.
9. Return the compressor to normal operation.
4.25.4.4 DC-DC Torque Specifications
Table 4-39 DC-DC Torque Specifications
Description Nm Ft.Lb. In.Lb.
Soft Start Mounting fastener, M5x15 5 - 44
DC-DC Mounting fastener, M3x10 0.5 - 4
Cover fastener, M5x15 1.5 - 13
