Figure 2-3 Split Cooling Path - TTH375/TGH285
Figure 2-4 Split Cooling Path - (TTS/TGS (Except TTS300/TGS230 Serial Cooling)
High-Li� Cooling Circuit
Flow Diagram
Inverter
SCR
BMCC
Inlet
(Liquid Refrigerant)
Inverter Temp Sensor
Impeller
1
st
Stage
Impeller
2
nd
Stage
Radial
Bearing
Axial Bearing
Stator/Rotor
Radial
Bearing
Solenoid
E
Solenoid
M
Motor Cavity
Temp. Sensor
BMCC
From Motor
Cavity Temp.
Sensor
From Motor
Winding Temp.
Sensor
Motor/Rotor
cooling gas and
leakage
BMCC
From Inverter
Temp. Sensor
From SCR
Temp. Sensor
Inverter
SCR
ORIFICE
ORIFICE
Solenoid
E
Solenoid
M
Liquid
Refrigerant
Inlet
