Danfoss Turbocor TTS Series User Manual

198 of 282 M-SV-001-EN Rev. G
7. Remove the three (3) M10x16 fasteners and ring terminal connections from the feedthrough
in order to be able to release feedthrough assembly. Refer to "Figure 4-252 High-Power
Feedthrough (PPS)".
Figure 4-252 High-Power Feedthrough (PPS)
8. Remove the three (3) M10 nuts, lock washers, and ring terminal connections from the
feedthrough in order to be able to release feedthrough assembly. Refer to "Figure 4-253 High-
Power Feedthrough Removal (stainless steel)".
Figure 4-253 High-Power Feedthrough Removal (stainless steel)
O-ring
(3 places)
High-Power
Feedthrough
(3 places)
Ring Terminal
to Feedthrough
Fastener,
M10x16
(3 places)
Lock washer
(3 places)
Ring
Terminal
(3 places)
Thermistor
terminal
(3 places)
Lock washer
(3 places)
High-Power
Feedthrough
(3 places)
Ring Terminal
to Feedthrough
nut, M10
(3 places)
Lock washer
(3 places)
O-ring
(3 places)
Motor Bus Bar
to Feedthrough
nut, M10
(3 places)
Inner M10 nut
Not torqued
(3 places)
Ring Terminal
(3 places)
Thermistor
terminal
(3 places)
