164 of 282 M-SV-001-EN Rev. G
4.22.6 DC Capacitor Bus Bar Assembly Torque Specifications
Table 4-34 DC Capacitor Bus Bar Assembly Torque Specifications
Description Nm Ft.Lb. In.Lb.
Soft Start DC+ & DC- to DC Bus Bolt/nut (TTS300/TGS230 only) 10 7 89
DC Capacitor Bus Bar to SCR Bus Bar Bolt (TTS300/TGS230 only) 10 7 89
DC Bus Bars to SCR fastener, M6x16 (TTS300/TGS230 only) 5 - 44
AC Bus Bar to SCR fastener, M8x20
(Excludes TTS300/TGS230 compressors)
9 - 80
Terminal Block Mounting fastener, M5x45
(Excludes TTS300/TGS230 compressors)
4 - 35
Capacitor DC Bus Bar to SCR fastener, M8x20
(Excludes TTS300/TGS230 compressors)
9 - 80
Mains Input Pressure Screw, 11/16" - 16 UNC
(TTS300/TGS230 compressors only)
20 15 177
Mains Input Nut, 3/8" - 16 UNC (excludes TTS300/TGS230 compressors) 21 15 186
Snubber Capacitor fastener, M6x16 7 - 62
Nylon Nut 7 - 62
Ground Post Top Nut, 5/16"-18 UNC 10 7 89
Ground Post Second (Jam) Nut, 5/16"-18 UNC 7 - 62
Cover fastener, M5x15 1.5 - 13
Cover Fastener, M5x20 (#3 on Capacitor Cover) 1.5 - 13
