155 of 282
M-SV-001-EN Rev. G
4.20.7 SCR Cooling Manifold Torque Specifications.
Table 4-33 SCR Cooling Manifold Torque Specifications.
Description Nm Ft.Lb. In.Lb.
TTS300/TGS230 AC Bus Bar to SCR fastener, M6x16 5 - 44
TTS300/TGS230 DC Bus Bars to SCR fastener, M6x16 5 - 44
DC Capacitor Bus Bar to SCR Bus Bar Bolt, M6 10 7 89
SCR to SCR Cooling Manifold fastener, M6x16 5 - 44
TTS300/TGS230 SCR Cooling Manifold Fastener, M6x20 7 - 62
TTS300/TGS230 Fuse to Terminal Block fastener 4 - 35
Soft Start Mounting fastener, M5X15 5 - 44
Ground Post Top Nut, 5/16"-18 UNC 10 7 89
Ground Post Second (Jam) Nut, 5/16"-18 UNC 7 - 62
Cover fastener, M5x15 - - 13
Snubber Capacitor fastener, M6x16 7 - 62
Nylon Capacitor Nuts 7 - 62
Terminal Block Mounting fastener, M5x45
(Excludes TTS300/TGS230 compressors)
4 - 35
AC Bus Bar to SCR fastener, M8x20
(Excludes TTS300/TGS230 compressors)
9 - 80
Capacitor DC Bus Bar to SCR fastener, M8x20
(Excludes TTS300/TGS230 compressors)
9 - 80
Mains Input Pressure Screw, 11/16" - 16 UNC
(TTS300/TGS230 compressors only)
20 15 177
Mains Input Nut, 3/8" - 16 UNC (excludes TT300/TG230 compressors) 21 15 186
SCR Cooling Manifold Fastener, M6x35
(Excludes TTS300/TGS230 compressors)
8.5 - 75
Inverter Assembly Mounting fastener, M6x30 8.5 - 75
