CALIBRATION
288 AV500/AV900 2D CAMERA
4. Other Important Application Dependent Parameters:
• Modify Settings | Global Settings | Object Detection (See section “Object Detec-
tion” on page 107)
• Modify Settings | Global Settings | Barcode Settings (See “Barc
ode Settings” on
page 111 )
• Modify Settings | Global Settings | Communications (See “Communications” on
p
age 139 )
• Modify Settings | Global Settings | Output Format (See “Output Format” on
p
age 151)
• Modify Settings | Global Settings | Image Saving (See “Image Saving”
on
page 160
)
Device Settings
In the menu tree under Modify Settings, navigate to Device Settings. Since each camera
is mounted separately, each AV500/AV900 camera in a system must be calibrated sepa-
rately.
There will be a different Device Settings branch in the menu tree for each camera in an
arr
ay.
See section “AV500 Device Settings” on page 170 for an explanation of the Device
Settings options.
1. In the menu tree, navigate to Modif
y Set
tings | Device Settings | Camera N |
Device Info. The Device Info window opens.
2. Enter a unique name for the camera; such as top left,
front right, etc. The new
name will appear in the Name column on the System Info window, and also in the
menu tree under Device Settings.
3. Click Update to save the new name. Repeat this for each camera in the system.
If there are several cameras in your array, you may want to label them appropriately.
