CONNECTING AN AV500/AV900 CAMERA
PRODUCT REFERENCE GUIDE
47
CONNECTING AN AV500/AV900 CAMERA
To install a camera, follow this sequence:
1. Complete mechanical installation (See “Mechanical Insta
llation” on page 28.)
2. Complete electrical installation.
3. Observe all electrical safety requirements outlined in this
chapter.
4. Ground the mounting structure to protective earth (PE) ground.
5. If used, wire the photoelectric sensor (or other trigger).
6. Wire the tachometer to the CBX connection box, (see “Encoder/Tachometer Wir-
ing to CBX510” on page 58).
7. Connect the M12 end of the Ethernet cable to the camera’s HOST NET port.
8. Connect to Ethernet device.
9. Connect the AV500/AV900 to its power supply.
10. Connect the sync cables if multiple cameras are used.
11. Connect the power supply to the power source.
12. Setup / check camera operations (See “Trigger, Positioning and Focusing Device
Setup” on page 270.)
To turn off your camera, use a power switch or box. Do not disconnect the 5 pin power
connection from the unit.
If you attach the power supply to t
he AV500/AV900 and it is already attached to power, it
may cause the AV500/AV900 to not boot correctly. Recycle power by unplugging the AC
cord from the power supply and plugging it back in.
