INTRODUCTION
4 AV500/AV900 2D CAMERA
Power and Sync Out LEDs Lit
LED Indicators
# LED Description
1
POWER
Solid Blue – Power LED indicating all internal power supplies are at the correct voltage. Can be
out i
f external power i
s supplied and an internal supply is out of range.
2 I/O
4 HOST NET
Red –
Host Network Data activity
NOTE
: With a Gbit link, Green will always be on and Red will blink, looking like it alternates Green
to amber. If connected to 100Mbit network, the LED will only blink Red with activity.
5 IMAGE NET
Red
– Image Network Data activity
NOTE: With a Gbit link, Green will always be on and Red will blink, looking like it alternates Green
to amber. If co
nnected to 100Mbit network, the LED will only blink Red with activity.
6 SYNC IN
Red
– SyncNet Data activity
NOTE
: With a 100Mbit link, Green will always be on and Red will blink, looking like it alternates
Green to amber. If connected to 100Mbit network, the LED will on
ly blink Red with activity.
9 SYNC OUT
Red – SyncNet Data activity
NOTE
: With a 100Mbit link, Green will always be on and Red will blink, looking like it alternates
Green to amber. If connected to 100Mbit network, the LED will on
ly blink Red with activity.
Solid Green – Indicates CBX box connected has the ID+ to GND jumper and this camera is the
controller for the tunnel. The Tachometer/Encoder must be connected to this unit.
Green - Host Network Link at Gbit speed
Green - Image Network Link at Gbit speed
Green - SyncNet Link at 100Mbit speed
Green - SyncNet Link at 100Mbit speed
