INTRODUCTION
16 AV500/AV900 2D CAMERA
Default Parameters
The user shall be able to default the parameters with the express button on power up,
This procedure is as follows:
1. Press and hold Xpress button and apply power to the unit.
2. The unit will recognize the button press within 15 seconds and blink all five LEDs
three times (once per second)
3
. Release the Xpress button once the LED’s start blinking
4. All 5 LEDs will turn off after 3 blinks
5. Press and release the Xpress button again within 5 seconds (all
LEDs will turn on)
6. All 5 LEDs will blink 3 more times to confirm parameter defaulting will take place
7. Normal LED boot sequence will take place
8. All 5 LEDs will start blinking after the boot sequence finishes. Blinking will c
on-
tinue until the parameters are defaulted
9. If you are connected to e-Genius you will notice that the RTP will report the fol-
lowing “critical” message to the web interface until the default sequence is com-
pleted: "W
aiting for Xpress Parameter Default to Complete"
10. The f
ollowing error will be reported if the RTP requests an Xpress default but the
COMe
does not know about it "Xpress parameter default requested but ignored"
If the Xpress button is still pressed after the blink sequence ends, the default request
will be ignored.
Failure to press the Xpress button within 5 seconds will result in the default request
being ignored.
