X-PRESS FUNCTIONALITY
PRODUCT REFERENCE GUIDE
17
Accessories
The follo
wing accessories are a
vailable on
r
equest for the A
V500/
A
V900 Camer
a Imag
-
ing Sys
tem.
Reflecting Mir
ror
P
/N 93ACC0086 (380mm) or 93ACC0116 (60
0mm)
Ethernet Connection Cable (M12-IP67 to RJ45)
This cable may be connect
ed to the Host or Imag
e port.
P
/N: 93A050034 (1m)
P
/N: 93A050035 (3m)
P
/N: 93A050036 (5m)
P
/N: 93A051389
(10m)
The reflecting mir
ror is used to reduce the footprint of y
o
ur system.
36
38
