ACCESSING E-GENIUS
PRODUCT REFERENCE GUIDE
79
Accessing e-Genius
To access e-Genius:
1. Connect your computer to the AV500/AV900 HOST NET, IMAGE NET or SYNC NET
port using an M12 to RJ45 Ethernet cable.
2. Turn on your laptop computer.
3. Configure your PC’s IP Address to be in the
same netw
ork as the port you are con-
nected to. See “To change your PC’s IP Address:” on page 80.
4. Open a web browser and enter the IP address for the unit. If the correct IP address
is enter
ed, the Log On window appears.
The default setup IP address for all AV500/AV900 cameras is: 192.168.0.145 (setup/sync
controller), 192.168.3.10 (Host), and 10.0.40.20 (Image).
5. Enter the User ID (default is setup) and Pa
ssword (default is DLAset) for your sys-
tem in the fields provided. Your site administrator may have modified these
defaults.
6. Sele
ct a language from the Language drop-down list.
7. Select METRIC or IMPERIA
L from the Units drop-down lis
t. All parameters which
require units of measure will be in the option you select, unless otherwise speci-
fied.
8. Click Log On.
If the user name and password are valid, the application enables all functions available
to the
user and displays the System Info window.
If the password is not valid, the application displays a results box with the message,
“Incorrect P
assword.” Click OK to return to the Log On window and enter the correct
user name and password. If you don’t know the password, contact your system man-
ager.
Before starting up or testing the camera, it must be connected to a CBX Connection Box
depending on the system configuration. Since Host and Image IP ports have static IP
addresses, they may have changed from their default addresses. Contact your IT
department to acquire the correct IP address.
The user ID and password shown above provide full setup rights to the user.
If a user only needs to view system information without saving changes, the User ID: monitor
and Password: DLAmon should be used.
